Hogg RL60 Wheelchair Stair Lift

SKU:
RL-60
1 300 734 862 Talk with an expert
Visit our Store
1 Mitchell St. Marrickville Sydney, Monday to Thursday
8:30am to 5:00pm
Friday 8:30am to 4:00pm

The Hoegg RL60 is a unique solution for the wheelchair user to be completely independent and mobile.  The sturdy design of the ceiling lift ensures comfortable transportation between different floors whilst meeting the highest safety standard.

Features

Boarding, departure and parking areas can be adapted to suit your needs and local conditions.
Attaching the wheelchair to the ceiling lift is simple and does not require physical strength.
Operating the lift is easy and has been designed for users and attendants with poor motor skills. The ergonomic control is customisable with a few simple steps.
The RL60 can be easily installed for use in narrow staircases with a steep incline. It can be fitted to standard, concrete and timber ceilings.
The rail guide can also be installed through doorways allowing greater accessibility and flexibility.

Inclusions
Wheelchair attachment bracket

Options
Platform: This is attached directly to the slings. The user drives onto the platform and secures themselves with a belt.
Cordless Station: Ideal for calling and sending the lift

Technical Facts
Manufacturer Hogg Liftsysteme AG, Switzerland
Nominal load 160kg. 250kg optional
Speed: Max. 0.15m/sec
Minimum Stair Width 810mm
Inclination Range 0 degrees (horizontal) to 60 degrees
Controls Key Switch
Hold-on Scanner (pressure scanner)
Emergency Stop
Drive System 37V CA / pinion on chain
Electrical Connection 230V CA. Fuse 13A
Rail Aluminium
Technical Conformity CE/TUV approved
